Voigtlander 35mm F1.2 II VM Mount Nokton Lens

The Voigtlander 50mm f3.5 APO-LANTHAR Type I is an extremely high performance manual focus standard lens optimized for full frame VM mount cameras. The apochromatic design thoroughly eliminates chromatic aberration on axis and other aberrations, while pursuing ultimate performance in terms of resolution and contrast reproduction. While adopting a maximum aperture of F3.5, the lens is composed of eight elements in six groups, four of which are made of anomalous partial dispersion glass to achieve uncompromising optical performance.

The lens combines ultimate optical performance with easy handling and classic vintage rangefinder lens styling. As a tribute to classic rangefinder lenses that appeared in the mid 20th century, the more expensive vintage style straight slot screw heads were chosen instead of less expensive modern Phillips head.

Equipped with a high precision rangefinder linked mechanism, and the silky feel of the all metal helicoid allowing the photographer to experience the true joy of focusing using a traditional rangefinder. The minimum focusing distance of the Type I is 0.45m. The rangefinder close focus is 0.7m (depending upon camera capability), which is linked to the rangefinder. A mechanism is provided to recognize the junction point of the rangefinder linked range by a clicking sensation during focusing operation.

The filter diameter is a retro inspired φ34mm. Two versions of Type I are available: a two tone black paint and chrome model with a heavy feel using brass materials (body weight: 245g) and a lightweight model with a matte black paint and aluminium construction (body weight: 150g). Each version includes a metal hood and a metal cap with the same finish as the lens body.

Wide-angle pancake lens

Focal Length: 21 mm
Aperture Ratio: 1:4,0
Minimum Aperture: F 22
Lens Construction: 8 elements in 6 groups
Angle of View: 91?
Aperture Blades: 10
Minimum Focus: 0,5 m
Maximum Diameter: 55 mm
Length: 25,4 mm
Mount: M-Bajonett (VM)
Weight: 136 g
Filter Size: 39 mm
Color: black

The NOKTON Vintage Line 35mm F1.5 Aspherical is a regular use lens for rangefinder cameras with a large aperture. Still, the filter diameter is kept to φ39mm and the overall length of the product is short at 36mm, giving it a tight, compact portability.

The lens barrel, with a modern classic design, is equipped with a 6-group, 9-element optical system featuring two double-sided aspheric lenses, which provide excellent optical performance at all apertures.

The minimum focusing distance is 0.5m, shorter than the 0.7m linked to the rangefinder (depending on the camera to which it is attached).

Two styles are available: First, there is Type I, made of aluminum and weighing 188g having both light weight and maximum portability. Also offered is Type II, made of brass and weighing 284g for a sturdy and substantial feeling, with a finish choice of either black or silver.

The optional hoods LH-4N with slits and LH-12 classic style are both compatible.

The Voigtlander 50mm f3.5 APO-LANTHAR Type II is an extremely high performance manual focus standard lens optimized for full frame VM mount cameras. The apochromatic design thoroughly eliminates chromatic aberration on axis and other aberrations, while pursuing ultimate performance in terms of resolution and contrast reproduction. While adopting a maximum aperture of F3.5, the lens is composed of eight elements in six groups, four of which are made of anomalous partial dispersion glass to achieve uncompromising optical performance.

The lens combines ultimate optical performance with easy handling and classic vintage rangefinder lens styling. As a tribute to classic rangefinder lenses that appeared in the mid 20th century, the more expensive vintage style straight slot screw heads were chosen instead of less expensive modern Phillips head.

Equipped with a high precision rangefinder controlled mechanism, and the silky feel of the all metal helicoid allowing the photographer to experience the true joy of focusing using a traditional rangefinder. The minimum focusing distance of the Type II is 0.35m by adopting a helicoid with a lens rotation angle of 300 degrees, which is rangefinder coupled as close as 0.7m (depending upon camera capability).

A mechanism is provided to recognize the junction point of the rangefinder linked range by a clicking sensation during focusing operation. The Type II filter size is φ39mm, a popular filter size for rangefinder cameras. Two versions of Type II are available: a silver version with a heavy feel using brass materials (body weight: 250 g) and a black painted model with a lighter weight by using aluminium materials in some parts (body weight: 175 g). The silver model has a metal hood in the same color as the main body and a black metal cap with a pear finish, while the black model has a black paint in the same color as the lens body.

The NOKTON Vintage Line 28mm F1.5 Aspherical is a wide-angle lens that combines three elements: a

large aperture, compact dimensions, and outstanding optical performance. The lens is F1.5, very fast for a

28mm wide-angle lens, with compact 43mm filter diameter and 45.5mm length for portability.

The classically designed lens barrel is equipped with an 8-group, 10-element optical system featuring two

aspherical lens elements on both sides. This delivers outstanding optical performance even at an aperture of

f/1.5.

The minimum focusing distance is 0.5m by the use of a helicoid that can be moved out further from the 0.7m

distance (depending on the camera) linked to the rangefinder.

Two different styles will be offered: The Type I is made of aluminum and weighs 250g. The Type II is made of

brass and has a tactile quality due to its hefty weight of 330g. The Type I styling is reminiscent of modern

classic lenses of the 1970s in matte black paint or silver, while the Type II, reminds us of the famous lenses

of the 1960s and is available in both black paint and silver finishes. The optional lens hood with slits, LH-6

fits both Type I and Type II styles.

In addition to this, the Type II includes a focusing knob that offers a new manual focusing experience. The

accessory knob can be exchanged on the focusing lever by unscrewing the screw in the finger recess and

reattaching with new knob. The focusing knob is metal and focuses the lens at approximately 1 meter from

the lens mount when turned to the 6 o'clock position, allowing the user to zone focus by the angle of the

knob.

The optical design of this lens is optimized for use with rangefinder-coupled digital and film cameras. It also

may be used on mirrorless cameras through the use of a mount adapter, making it suitable for use on a

variety of platforms beyond rangefinder cameras.

The Voigtlander 21mm f3.5 VM ASPH Vintage Line Color-Skopar Type II Lens is a newly designed compact super wide lens.

Main Features

¦ Classical styling reminiscent of the 1970s

¦ Element with aspherical surfaces ensures excellent performance from maximum aperture

¦ Extremely solid and durable all-metal barrel

¦ Manual focus for precise focusing

¦ Aperture mechanism with 10 aperture blades for beautiful bokeh

¦ Bayonet type VM-mount

The optional LH-11 lens hood manufactured from aluminium feature a bayonet mount for quick attachment / removal and crystal paint highly valued for its classical texture.
